# Basic Config
esphome:
  name: KC868-Uair

esp32:
  board: esp32dev
  framework:
    type: arduino

# Enable logging
logger:

# Enable Home Assistant API
api:
  encryption:
    key: "hx8eSqbwjWs9/2bK0qK55QfTIOpI4gCfzLOeaOXZMaU="

i2c:
  sda: 4
  scl: 16
  scan: true
  id: bus_a

# Example configuration entry
one_wire:
  - pin: GPIO27
    update_interval: 15s

# Individual sensors
sensor:
  - platform: dallas_temp
    address: 0xC000000004D81528
    name: "internal Temperature"

# Example configuration entry
  - platform: sht3xd
    temperature:
      name: "extend Temperature"
    humidity:
      name: "extend Humidity"
    address: 0x44
    update_interval: 15s

light:
  - platform: esp32_rmt_led_strip
    chipset: ws2812
    pin: GPIO32    # Pin Define connected with LED strip
    num_leds: 4  #LEDs number
    rgb_order: GRB
    name: "Uair-Bottom-LED"
    effects:
      - addressable_rainbow:        ##defined 7 effects styles
      - addressable_color_wipe:
      - addressable_scan:
      - addressable_twinkle:
      - addressable_random_twinkle:
      - addressable_fireworks:
      - addressable_flicker:

  - platform: esp32_rmt_led_strip
    chipset: ws2812
    pin: GPIO33    # Pin Define connected with LED strip
    num_leds: 1  #LEDs number
    rgb_order: RGB
    name: "Uair-VVertical-LED"
    effects:
      - addressable_rainbow:        ##defined 7 effects styles
      - addressable_color_wipe:
      - addressable_scan:
      - addressable_twinkle:
      - addressable_random_twinkle:
      - addressable_fireworks:
      - addressable_flicker:
